Baja Designs
Baja Designs Squadron Pro - Pair
Style
Choose options
Style
Style
Satisfactions Guarantee – 30 Day Money Back Guarantee Limited Lifetime Warranty – Complete Purchase Protection uService ® – Replaceable Lenses And Optics ClearView ® MoistureBlock ™ CopperDrive ® – Only LED Driven At 100% 5000K Daylight 26W / 2A 3.07" x 2.77" x 3.07" 12 ounces Hard Coated Polycarbonate Powder Coated Cast Aluminum Billet Machined Aluminum Stainless Steel Exceeds MIL-STD810G (Mil-Spec Testing) Built-In Overvoltage Protection IK10 Compliant (Mechanical Impact Testing) (2) Squadron® Sport LED Lights Mounting Brackets Wiring Harness Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Driving (42°) and spot (9°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3) A longer and narrower 9° beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights. (Lighting Zone 4 & 5) Excellent work light or “scene light” with an extremely smooth 120° circle that projects about 40ft. This pattern is not suitable for driving. (Lighting Zone 7)
- Baja Designs Features:
- – All The Light, Right Where You Need It.
- – Waterproof, Rain Proof, Submersible
- – Less Driver Fatigue, Natural Color
- Specifications (per light):
- Lumens:
- 3,150 Utilizing 4 LEDs
- Wattage/Amps:
- Dimensions:
- Weight:
- LED Life Expectancy:
- 49,930 Hours
- Front Lens:
- Housing:
- Bezel:
- Hardware & Bracket Material:
- IP69K (Waterproof, Submersible to 9ft)
- Includes:
- Patterns:
- Driving/Combo:
- Wide Cornering:
- BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 42° flattened horizontal beam for the ultimate in comfort lighting. (Lighting Zones 1 & 2)
- Spot:
- Work/Scene:
